12V UPS Battery

Lead-acid batteries can be divided into wet batteries and dry batteries (or maintenance-free sealed lead-acid batteries SLA) according to the electrolyte form; according to the design and working principle, they can be divided into starting type batteries (car batteries) and energy storage type batteries (VRLA batteries). valve-regulated sealed lead-acid battery (VRLA), also known as the maintenance-free battery, is divided into two types: AGM battery and GEL battery. According to the usage, it can also be divided into UPS battery, solar energy battery Batteries, special batteries for ships, etc.

12V UPS battery

As top 10 brand in China, CPSY® products are famous with its good service and low fault rate, and have a good price advantage and cover most of the European and Asian markets. We look forward to becoming your long-term partner in China.

12V UPS battery is mainly composed of tubular positive plate, negative plate, electrolyte, separator, battery tank, battery cover, pole, liquid injection cover, etc. Compared with other brands of batteries, Shangyu CPSY® batteries have the advantages of sufficient capacity, stable voltage, low price, long service life and less daily maintenance. The general warranty is 1-3 years, and the warranty can be extended to 5 years. Lead-acid batteries are available in 2V, 6V, and 12V series with different capacities. From 7Ah to 3000Ah. The UPS battery is a rechargeable battery based on AGM (absorbent glass fiber board) technology and calcium grid plate. It has superior high current discharge characteristics and ultra-long service life. It does not require adding water during use. UPS batteries are widely used and can be used in power tools, emergency lights, UPS, electric wheelchairs, computers and communication equipment, etc.

CPSY® 12V UPS battery Parameter (Specification)

*Material of 12v ups Battery:

1.99.994% pure lead

2.A grade ABS fireproof/waterproof case

3.Good copper teminal

4.Sulfuric acid electrolyte

*Instructure of 12v ups Battery:

- Radial pattern grid, compact assembly design, high discharge efficiency

- 4BS lead paste, long service life

- Unique alloyed grid with powerful corrosion capability, excellent recovery capability

- High purity raw materials to minimize the self-discharge rate

- Unique gas-recombination technique, completely sealing design, safe to use and environment friendly

- Excellent and reliable sealing technique, save to use

CPSY® 12V UPS battery Feature And Application

Features:

1.The cycle charging capacity is 3 times higher than that of lead-calcium batteries and has a longer service life.

2.Higher capacitance stability throughout the service life cycle,

3.The probability of acid leakage is small, the water loss is small, and the low-temperature performance is more reliable.

4.Reduce the risk of accidents and reduce the risk of environmental pollution (because the acid is 100% sealed)

5.Maintenance is very simple, strong resistance to overcharge, and reduced deep discharge.

6.The self-discharge performance is good. Under the same sulfuric acid purity and water quality conditions, the storage time of the battery can be extended by more than 2 times.

7.In the case of severe power shortage, the anti-sulfurization performance is obvious.

8.Strong recovery ability under severe discharge conditions, effectively extending battery life.

Application Fields:

- Electric vehicle

- Solar power system, wind power system

- Electronic device

- Other dynamic field

- UPS

CPSY® 12V UPS battery Details

Lead-acid batteries are available in 2V, 6V, and 12V series with different capacities. From 7Ah to 3000Ah. The UPS battery is a rechargeable battery based on AGM (absorbent glass fiber board) technology and calcium grid plate. It has superior high current discharge characteristics and ultra-long service life. It does not require adding water during use. UPS batteries are widely used and can be used in power tools, emergency lights, UPS, electric wheelchairs, computers and communication equipment, etc.

CPSY® 12V ups battery is with full capacity, never happen quality problem.

we have strict control quality in the battery produce process,every battery will be check before leaving factory.

We use the best materila(see belowing ) in our battery to ensure its long life span:

1.ABS container --------------- fire resistance(UL94HB and UL 94-0ABS) and water proof,better than PVC,etc.

2.99.997% pure lead -----------more better than the 60%-70%lead or recycling lead,and use long time.

3.Pure Copper terminals--------good conductive properties,better than normal copper terminal.

4.AGM material separator-------absorb the moisture in the adverse factors, more stable & durable than PP/PE/PVC separator.

5.Silicone safety valve----------Corrosion, discharge excess gas, explosion-proof

6.Silicone GEL electrolyte:------Import from Germany Evonik Degussy silicone, international famous brand.

7. the GEL in CPSY POWER GEL battery is import from Germany Evonik Degussa, international famous brand.

Those factors effect battery its cost and functions, and this is from a technical point of view to proof it.

UPS battery from 12V7Ah ~ 12V/200Ah

Shangyu (Shenzhen) Technology Co., Ltd. is a technology-type enterprise focusing on uninterruptible power supply systems and new energy smart products.CPSY® factory produces not only all kinds of ups products(line interactive UPS,rack mount ups,high frequency online ups,low frequency ups,modular ups) , all kinds of precision air conditioner, but also ups battery, charging pile,etc. High-end produce with good quality,high-end technology with best service.

Capacity: from 12V7Ah ~ 12V/200Ah

Supply Capacity:20000pcs/month

Min.order: One 20'Container(accepted mix. model)for OEM order, 8pcs with each battery model for CPSY brand.

Trade term: EXW factory price,CIF price or FOB Shenzhen price

Packing details: 1pc battery + a pair of foams+ warranty card*1 + terminals in a carton box , then in wooden pallet.

Delivery time: After receiving the deposit or 100% full payment, sample order about 7days, Mass production about 20-25days after received 30% deposit.

Payment term:T/T in advance, L/C At sight, Western Union/Paypal (for samples)

FOB price: USD dollar/RMB yuan

Near Seaport: Shenzhen
