Home Offline UPS

CPSY® Home Offline UPS is the latest invention of high-quality ups products, which comply with CE, ROHS, IEC, BS,UL,TUV, SAA standard and comes with a 2-year warranty. As a professional manufacturer of UPS and precision air conditioner, Our aim is continuously to offer our customer stable and reliable, clean and high-efficiency power.welcome to inquiry.

Send Inquiry

Product Description

The CPSY® Home Offline UPS is made of metal+ PCBA, which has been designed to meet most demanding power requirements, being easy to install and maintain. It combines latest high energy efficiency technology and high power density technology, achieving small size, stable performance and price competitive for UPS products.

The CPSY® Home Offline UPS is made of metal+ PCBA, which has been designed to meet most demanding power requirements, being easy to install and maintain. It combines latest high energy efficiency technology and high power density technology, achieving small size, stable performance and price competitive for UPS products.


CPSY® S series Home Offline UPS Parameter (Specification)

Model S500/S1550 S600/S650 S800/S850 S1000/S1050 S1200/S1250 S1500/S1550 S2000/S2050
Capacity 500VA/300W 600VA/360W 800VA/480W 1000VA/600W 1200VA/720W 1500VA/900W 2000VA/1200W
Input
Voltage 110/120VAC
Voltage Range 80-145VAC
Frequency Range 60/50Hz
Output
AC Voltage Regulation (Batt.Mode) 100-120AC
Frequency Range (Batt.Mode) 50H or 60Hz ±1Hz
Transfer time Typical: 2-8ms,10ms max.
Waveform (Batt.Mode) Simulated Sine wave
Battery
Battery Type & Number 12V7Ahx1pc 12V7Ah x 1pc 12V9Ah x 1pc 12V7Ah x 2pc 12V7Ah x 2pc 12V9Ah x 2pc 12V9Ah x 2pc
Typical Recharge Time 4-6 hours up to 90% capacity
Protection
Full Protection Overload,Discharge,and overcharge protection
Indicators
LCD display AC mode,battery mode,load level,input voltage,output voltage,overload,fault,and low battery
LED display AC Mode Green light
Battery Mode Green light
Alarm
Battery Mode Sounding every 10 seconds
Low Battery Sounding every seconds
Overload Sounding every 0.5 seconds
Fault Continuously sounding
Physical
Dimensions, D*W*H (mm) 185*100*140 325*146*185
Net Weight (KG) 4.5 4.5 5.1 9.2 9.2 10.9 10.9
Environment
Operation Humidity 0-90%RH@0-40℃(non-condensing)
Noise Level Less than 40dB
Management
Communication port Optional USB,RS232 communication port and RJ-11/RJ-45 Protection
Remark:  S500/S600/S800/S1000/S1200/S1500/S2000 with LED display
S550/S650/S850/S1050/S1250/S1550/S2050with LCD display


CPSY® Home Offline UPS 500-3000VA Feature And Application

KEY FEATURES

* Line-interactive UPS with super-long backup time

* wide input range with AVR function

* Protection for short circuits, overloads, and battery low voltage

* LED indication and audible alarm function

* Intelligent battery management

* with cold start function

* with AUTO restart function

* Automatic battery charging while UPS is off(Optional)

* USB+RJ11/RJ45 or RS232 port(optional)

Application: PC, Work station, Small communication equipment.



CPSY® Home Offline UPS 500-3000VA Details

When compare with peers, CPSY® Home Offline UPS 500-3000VA advantages as below:

●AVR function, high reliable

●Auto self-testing function when ups start

●UPS restart when AC power coming

●Smart charging, shorten 50% charging time when charge the battery.

●Super overload capacity, 120% load work for long time

●Battery auto charging function when UPS off

●Customized service, accept ODM & OEM order.

●Approve European CE and ROHS certification system

●Optional Plastic trype/Metal type/long-run type/charger type computer ups

●Optional anti-lighting function,More Safety.


Model No. 1Pallet 20GP 40GP 40HQ Remark
S500/S550 160 1600 3360 3780 180pcs max.
S600/S650 160 1600 3360 3780 180pcs max.
S800/S850 160 1600 3360 3780 180pcs max.
S1000/S1050(500w) 160 1600 3360 3780 180pcs max.
S1000/S1050(600w) 105 1050 2205 2520 120pcs max.
S1200/S1250 105 1050 2205 2520 120pcs max.
S1500/S1550 105 1050 2205 2520 120pcs max.
S2000/S2050 105 1050 2205 2520 120pcs max.


Why choose CPSY?

12+ years rich experience manufacturer, 2,5000 square meters, 300+ workers,more than 120 +patents

30+R & D Engineer keep to improve design and supply new products .

7 QC to controller the Full process,100% inspection before shipment .

TOP 5 manufacturer,Large batch production to guarantee competitive price.

We are the only manufacturer who can sign "Quality Warranty"&"On Time Delivery Warranty" with client.

One of the few supplier whom have factory to make the Key Products and also supply complete set system design and installation supporting

Support OEM/ODM service with LOW MOQ!

10 years experience in international bidding together with dealer.

Annually train to dealer office or in factory about design/installation and maintenance.


Important Safety Warning for Computer UPS (SAVE THESE INSTRUCTIONS)

CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants. (See the specifications for the acceptable temperature and humidity range.)

CAUTION! To reduce the risk of overheating the UPS, do not cover the Ups' cooling vents and avoid exposing the unit to direct sunlight or installing the unit near heat emitting appliances such as space heaters or furnaces.

CAUTION! Do not attach non-computer-related items, such as medical equipment,life-support equipment, microwave ovens, or vacuum cleaners to UPS.

CAUTION! Do not plug the Ups input into its own output.

CAUTION! Do not allow liquids or any foreign object to enter the UPS. Do not place beverages or any other liquid-containing vessels on or near the unit.

CAUTION! In the event of an emergency, press the OFF button and disconnect the power cord from the AC power supply to properly disable the UPS.

CAUTION! Do not attach a power strip or surge suppressor to the UPS.

CAUTION! If the UPS is with metal chassis, for safety purpose, grounding is a must during UPS installation in order to reduce leakage current below 3.5mA.

Attention! hazardous through electric shock. Also with disconnection of this unit from the mains, hazardous voltage still may be accessible through supply from battery. The battery supply should be therefore disconnected in the plus and minus pole at the quick connectors of the battery when maintenance or service work inside the UPS is necessary.

CAUTION! Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions.Keep unauthorized personnel away from batteries.

CAUTION! When replacing the batteries, use the same number and type of batteries.

CAUTION! Internal battery voltage is 12VDC, Sealed, lead-acid, 6-cell battery.

CAUTION! Do not dispose of batteries in a fire. The battery may explode. Do not open or mutilate the battery or batteries. Released electrolyte is harmful to the skin and eyes.

CAUTION! Unplug the Ups prior to cleaning and do not use liquid or spray detergent.

CAUTION! A battery can present a risk of electric shock and high short circuit current. The following precaution should be observed before replacing batteries:

1) Remove watches, rings, or other metal objects.

2) Use tools with insulated handles.

3) Wear rubber gloves and boots.

4) Do not lay tools or metal parts on top of batteries.

5) Disconnect charging source prior to connecting or disconnecting batteries terminal.
